Specification
- Sub-6 GHz or mmWave frequency compatible
- Built-in 5G NR NSA and SA module, 5G NR and LTE-A Cat 20+ Dual mode module
- Support both NSA and SA modes
- 3 Ethernet Ports
- 802.11n and 802.11ac Dual-Band Wi-Fi with MU-MIMO, 802.11ax WIFI 6 with MU-MIMO
- 4 external antennas for LTE/5G NR
- FOTA and TR069
- Supports VoLTE and VoIP
Item | Description |
CPU | IPQ 8072+QCN5054+QCN5024+PMP8074 |
PLC | QCA7550 (optional) |
WAN/LAN(GE) | 8081+8075 |
5G Chipset | Qualcomm X55 |
Memory | 128M/256M , 1G SDRAM (DDR4) |
Antenna Type | 2.4G:4T4R 5.8G:4T4R |
Protocol | 802.11 ax WIFI 6 |
Antenna Gain | Build-in antenna，the gain up to 2-5dBi |
Interface | 1*SIM 1*USB3.0 3*1000Mbps LAN 2*1000Mbs WAN 1* RJ11 |
Storage | 500G 2.5-inch disk (Optional) (SATA interface) |
PLC | ≥1000Mbps |
Mesh | Support |
Power Supply | DC 12V/3A |
LED | Power WIFI (2.4G) WIFI (5G) 4G 5G |
Buttons | 1*Reset 1*WPS |
5G | Description | |
5G NR | n1/n2/n3/n5/n7/n8/n20/n28/n41/n66/ n71/n77/n78/n79 | |
LTE | B1/B2/B3/B4(66)/B5(18/19/26)/B7/B8/ B12(17)/B13/B14/B20/B25/B26/B28/ B29/B30/B38/B39/B40/B41/B42/B43/ B46/ B48/B71 | |
Protocols | PPP/QMI/NTP*/TCP*/UDP*/FTP*/HTTP*/PING*/HTTPS*/SMTP*/MMS*/FTPS*/SMTPS*/SSL* | |
Enhanced Features | Digital Audio and VoLTE (Voice over LTE) (Optional) (U)SIM Card Detection DFOTA: Delta Firmware Upgrade Over-the-Air GNSS: GPS/GLONASS/BeiDou/Galileo Embedded eUICC | |
DL 4X4 MIMO | 5G NR | n1/n2/n3/n7/n41/n66/n77/n78/n79 |
LTE | B1/B2/B3/B4/B7/B25/B30/B38/B39/ B40/B41/B42/B43/B48/B66 | |
WCDMA | B1/B2/B3/B4/B5/B8/B9/B19 | |
5G | 5G NR standard | Sub-6GHz, 3GPP, Rel15 |
Operation mode | NSA&SA | |
Modulation | UL: 64 QAM; DL: 256 QAM | |
CA support | DLCA | |
MIMO | DL: 4 × 4 MIMO; UL: 2 × 2 MIMO | |
Data Rate | 5G | Downlink up to 2.8Gbps; Uplink:190Mbps |
4G | 3GPP Downlink/Uplink up to 150Mbps/50Mbps | |
3G | 3GPP Downlink/Uplink up to 42Mbps/5.76Mbps | |
