Specification
- LTE CAT4 Support
- Maximum 150Mbps Downlink 50Mbps Uplink On LTE
- Qualcomm MDM9207
- WiFi 2.4GHz , 802.11b/g/n
- 2200mAh battery, More than 7 hours working time
- Android / iOS App Management
- Supports FOTA and TR069
| Basical Information | Model Name | R776 |
| Form Factor | Mobile WiFi | |
| Dimension | 99*60*(14.5/16.5)mm | |
| Weight | about 80(110)g | |
| Color | White+Gray | |
| Launch time(PP) | 2019.7 | |
| Air Interface | Technical Standard | Compatible with WCDMA, FDD-LTE,TDD-LTE 802.11 b/g/n |
| Frequency | Support global frequency bands: Default: FDD :B1/B3/B7/B8/B20/B28 TDD: B38/B40/B41 3G:B1/B8 Option 1: FDD B1/B3/B5/B18/B19/B7/B8/B20 TDD:B38/B40/B41 3G:B1/B3/B5/B6/B8/B19 Option 2: FDD B2/B4/B17/B28 3G:B2/B5 | |
| WIFI | 2.4G, WIFI 1*1 802.11 b/g/n | |
| Performance | Maximum Data Throughput | LTE CAT 4 FDD-LTE 150Mbps/50Mbps |
| Hardware | Receive Diversity | Support Receive Diversity |
| MIMO | Support DL 2×2 MIMO | |
| BB Chipset | Qualcomm MDM9207 | |
| RF Chipset | Qualcomm WTR2965 | |
| WiFi Chipset | Realtek 8189 | |
| Memory | 2Gb+1Gb | |
| T-card | NA | |
| USB Charging | above 5V/1A | |
| USIM/SIM | 3FF SIM card support SIM/USIM/UIM,standard 6 PIN SIM card interface, support 3V SIM card and 1.8V SIM card;internal | |
| Battery | Li-ion Battery 2200mAh | |
| Charging time | <3.5 hours | |
| Working time | up to 7h | |
| Standby time | 450h | |
| LED | 1)Power/Battery Status Indicator 2)4G/3G Network Status Indicator 3)New SMS Indicator | |
| USB | Charge & internet | |
| Antenna | Built-in | |
| Buttons | POWER，Reset, WPS | |
| Slic | NA | |
| BT | NA | |
| ESD | ESD Protection circuit, Contact±8KV,Air±10KV | |
| Software | UI | WebUI , Mobile WEB UI |
| Charge and discharge management of battery | Battery Indicator,Low power management and so on | |
| SW Update | Local Update, Fota | |
| WIFI Mode | AP | |
| WIFI Security | OPEN & WPA2-PSK & WPA-PSK/WPA2-PSK; | |
| SMS | Support | |
| Voice | NA | |
| AGPS | Not Support | |
| IPv4 | Support IPv4 | |
| IPv6 | Support IPv6 | |
| Firewall | Mac/IP address filter, Port forwarding, WiFi Black/Whilte list | |
| Data Statistics | Support | |
| VPN Pass Through | PP2P/L2TP/IPSec | |
| SIM Lock | Support | |
| SNTP | Support | |
| DOS ATTACK | Support | |
| DMZ | Support | |
| HTTP | Support | |
| HTTPS | Support | |
| Automatic APN matching according to USIM | Support | |
| Data Lock | Support | |
| Certification | Depends on customization, cost related | |
| Environment | Operating Temperature | Normal:-10°C to +45°C |
| Storage Temperature | -20° C to +70° C | |
| Humidity | 5%~ 95% |
